Five
inputs
Dual DAC
ES9028PRO
DSD512
PCM384
Linear
Power Supply
Femto
Clock
Fibre
Network

Why LUMIN P1 Mini

Just like its bigger brother, P1 Mini is designed to be used as a streamer, a DAC, a pre-amplifier or all three!

With 5 analogue and digital inputs, a linear power supply and many other components taken from flagship players, LUMIN P1 Mini packs incredible versatility and value into its new slim chassis.

Main features

  • Five inputs including USB, HDMI, SPDIF and Analogue
  • HDMI with stereo input + AV Passthrough & ARC
  • Dual DAC ES9028PRO
  • DSD512 & PCM384
  • Femto Clock System with precision FPGA distribution
  • New internal toroidal linear power supply
  • Dual Network with Optical Fibre Network support
  • Leedh Processing lossless volume control

5 digital & analogue inputs

Versatile enough for any audio or video stereo system:

USB

  • Industry-leading XMOS USB audio controller
  • Native DSD512 and PCM384 compatible
  • Windows 10 & Mac OS compatibility

Analogue

  • Stereo analogue input
  • LEEDH volume processing
  • Passthrough function for home cinema integration with custom naming functionaity

SPDIF Optical & RCA

  • DoP64 / 192 kHz 24-bit compatible
  • TOSLINK & SPDIF (RCA)

HDMI

  • HDMI 2.0 Specification compatible
  • Supports 2.0 PCM audio decoding
  • HDR, Dolby Vision, Dolby Atmos, DTS passthrough
  • ARC compatible output

X1 Heritage

LUMIN P1 Mini takes many flagship features from the outstanding LUMIN X1:

Fibre Networking

A world-first on X1 and now featured on many LUMIN models, optical networking provides complete isolation from network noise. Additionally, dual network ports mean that you can connect LUMIN L2 or a NAS directly to P1 Mini.

Femto Clocking System

P1 Mini includes dual Femto crystal oscillators and our proprietary FPGA clock distribution system first debuted in X1.

Included Remote Control

A tactile infrared remote control allows easy change of input, volume adjustment, playlist navigation and more.

The exceptionally well-constructed acrylic and zinc LUMIN remote is made in Austria and is entirely Roon Ready.

LUMIN P1 Mini has a built-in infrared receiver and is compatible with universal remote controls, phones and automation systems.

Flexible setup options

Use as a streamer, a DAC, a pre-amplifier or all three!

Idea 1 - Streaming DAC

LUMIN P1 Mini can be used like all other LUMIN players. With its DSD512/PCM384 support, Femto Clock System, Fibre Networking, toroidal power supply, and Leedh Processing, it's packed with incredible components.

Idea 2 - Hi-Fi Hub

Connect all your stereo sources to LUMIN P1 Mini and attach a power amplifier and you've got everything you need for an incredible music system.

Idea 3 - 2-channel TV System

No need for an AV Receiver. Simply attach your HDMI sources to your TV and P1 Mini to your TV. With HDMI ARC, all your audio comes through your main speakers.

Supported Streaming Services

TIDAL TIDAL Connect Qobuz Roon Spotify Plays with Audirvana KKBox QQMusic Plex MQA AirPlay-compatible TuneIn Multi-Room

Leedh Processing Digital Volume Control

Leedh-processing Read more
LUMIN P1 Mini

Specification

P1 Mini Specification highlights

  • Network playback:

    • Up to DSD512
    • Up to 384 kHz, 16–32-bit, Stereo
    • MQA Full Decoding

  • Upsampling rates & bit depths:

    • DSD256 upsampling option for all files
    • PCM 384kHz upsampling option for all files

  • Digital Input:

    • USB:
      • USB Audio Class 2 Compatible
      • WINDOWS 10 (Release 1703 or above) / Mac OSX or above
      • DoP 128 support
      • PCM 44.1–384 kHz, 16 / 32-bit, Stereo
    • OPTICAL/SPDIF:
      • PCM 44.1 kHz–192 kHz, 16–24-bit
      • DSD64 (DoP64, DSD over PCM)
    • HDMI:
      • PCM 2.0 Audio support
      • 4K Video Passthrough

  • Digital Output:

    • USB:
      • Native DSD512 support
      • PCM 44.1–384 kHz, 16–32-bit, Stereo
    • BNC SPDIF:
      • PCM 44.1 kHz–192 kHz, 16–24-bit
      • DSD64 (DoP64, DSD over PCM)
    • HDMI:(HDMI Passthrough and ARC support)
      • PCM 2.0 Audio support
      • 4K Video Passthrough
      • ARC (Audio Return Channel) support

  • Analogue Input:

    • RCA Stereo x1

  • Analog Output:

    • Dual ESS SABRE32 ES9028Pro DAC chips
    • Fully balanced layout with high-quality components
    • Femto Clock System with precision FPGA distribution

  • Optical Network:

    • Industry-standard Gigabit SFP
    • 1000Base-T Gigabit Ethernet
    • Adapter may be needed for your particular switch/cables
    • Use simultaneously with RJ45 (e.g. connect one to router and one to LUMIN L1 or NAS)

  • Power Supply:

    • Internal toroidal linear
    • Low-noise linear regulator

  • Physical:

    • Finish:

      • Black anodised aluminium
      • Raw anodised aluminium

      Lumin (solid aluminium chassis):

      • 400mm (W), 314mm (D), 77mm (H), 7kg

Specification for all current-gen LUMIN streamers

  • Streaming Protocol:

    • UPnP AV protocol with audio streaming extension (OpenHome)
    • Roon Ready
    • TIDAL Connect
    • Spotify Connect
    • Flac lossless Radio stations
    • Plāys with Audirvāna
    • AirPlay-compatible
    • QPlay-compatible for QQMusic
    • Gapless Playback
    • On-Device Playlist

  • App Features:

    • Native support for TIDAL, MQA, Qobuz, KKBox and TuneIn Radio.
    • Tidal MAX and MQA icons to identify high-res music
    • Qobuz high-res icons to identify high-res music
    • Volume control
    • High-resolution artwork
    • Artwork caching
    • Search
    • Multiple tag handling
    • Composer tag support
    • Album-grouping in playlist
    • Automatic internet links to artists/album/songs
    • Saving and restoring of playlists (including Tidal and Qobuz)

  • Supported Audio File Formats:

    • DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD)
    • PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFF
    • Compressed (lossy) Audio: MP3
    • MQA

  • Input:

    • Gigabit Ethernet Network (1000BASE-T) RJ45
    • Shared USB port can also be used for storage, flash drive, USB hard disk (Single-partition FAT32, exFAT and NTFS only)

  • Analogue Audio Outputs:

    • XLR balanced, 6Vrms, pin 2 Hot
    • RCA unbalanced, 3Vrms

  • Supported Control Devices:

    • Apple devices. iOS 11.0 or later (List of supported devices)
    • Android devices. Android 4.0 (Ice Cream Sandwich) or later required
    • Apple Silicon. macOS 11 or later. (Download the iOS App from the iOS App Store)
    • Chromebook. Google Play Store required.

  • Other:

    • Leedh Processing lossless digital volume control
    • Programme of Continuous Development – Firmware-upgradable for further features and enhancements

Product Downloads & Links
