X1 Power Supply
upgrade
Solid billet
CNC PSU casing
Matches the
main U1 chassis
Low-noise
linear
regulator
DSD512
PCM768
5 types
of output

Why LUMIN U1X

With our flagship PSU becoming available as an upgrade to other models, many customers requested a bundle including this new PSU as standard.

LUMIN U1X arrives already-upgraded, with the X1 PSU included in the box.

Not only will you benefit from its sleeker finish and heavyweight solid-billet construction, owners are reporting improvements to every aspect of their favourite music.

Upgrade features

  • No need for add-on upgrades
  • Power supply uses the same solid billet construction techniques as the main U1 chassis
  • Thick aluminium walls provide even more shielding
  • Available in anodised black and raw silver
  • Supplied with a custom version of the X1 cable
  • Separate digital and analogue circuitry
  • Low-noise Linear Regulator
  • The highest quality components used throughout

LUMIN U1X features

  • 5 types of digital audio output including new USB
  • Includes DSD512 22.5Mhz 1-bit playback
  • PCM 44.1–768kHz 16–32-bit
  • 4 exceptionally low-phase-noise crystal clock oscillators
  • External dual-toroidal power supply
  • Resampling to every supported format up to DSD128 and PCM384kHz
  • Supports DoP (DSD over PCM) for Optical, Coaxial RCA, Coaxial BNC & AES/EUB SPDIF

All the usual LUMIN refinements

  • From MQA to DSD, FLAC to WAV, LUMIN can play all the high-resolution formats you could ever want
  • Native support for TIDAL, Qobuz, Spotify and AirPlay-compatible, giving you access to tens of millions of songs
  • The unique and intuitive LUMIN App described as "the most convenient interface in existence" by TINMAN
  • LUMIN programme of continuous development that has seen Roon, MQA, and Spotify support added in 2017 alone.

Read more

LUMIN U1

Specification

U1 Specification

  • DSD Support:

    • Up to DSD512 22.5MHz, 1-bit
  • PCM Support:

    • Up to 768kHz, 16–32-bit, Stereo
  • Upsampling rates & bit depths:

    • DSD128 upsampling option for all files
    • PCM 384kHz upsampling option for all files
  • Digital Output Stage:

    • USB:
      • DSD512 22.5MHz, 1-bit, Stereo
      • PCM 44.1–768kHz, 16–32-bit, Stereo
    • Optical, Coaxial RCA, Coaxial BNC & AES/EBU:
      • DSD (DoP, DSD over PCM) 2.8MHz, 1-bit
      • PCM 44.1kHz–192kHz, 16–24-bit
  • Power Supply:

    • External X1 CNC Billet dual-toroidal
    • Available in 240V and 110V versions
  • Physical:

    • Finish:

      • Raw brushed aluminium or black anodised brushed aluminium with matching Power Supply

      Lumin (solid aluminium chassis):

      • 350mm (W), 345mm (D), 60mm (H), 8kg
    • X1 PSU:

      • 106mm (W), 334mm (D), 60mm (H), 4kg

Specification for all LUMIN music streamers

  • Streaming Protocol:

    • UPnP AV protocol with audio streaming extension (OpenHome)
    • Roon Ready
    • TIDAL Connect
    • Spotify Connect
    • Flac lossless Radio stations
    • AirPlay-compatible
    • Gapless Playback
    • On-Device Playlist
  • App Features:

    • Native support for TIDAL, MQA, Qobuz and TuneIn Radio.
    • Tidal MAX and MQA icons to identify high-res music
    • Qobuz high-res icons to identify high-res music
    • Volume control
    • High-resolution artwork
    • Artwork caching
    • Search
    • Multiple tag handling
    • Composer tag support
    • Album-grouping in playlist
    • Automatic internet links to artists/album/songs
    • Saving and restoring of playlists (including Tidal and Qobuz)
  • Supported Audio File Formats:

    • DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD)
    • PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFF
    • Compressed (lossy) Audio: MP3
    • MQA (Core decode)
  • Input:

    • Ethernet RJ45 network 1000Base-T
    • USB storage, flash drive, USB hard disk (Single-partition FAT32, exFAT and NTFS only)
  • Supported Control Devices:

    • Apple devices. iOS 11.0 or later (List of supported devices)
    • Android devices. Android 4.0 (Ice Cream Sandwich) or later required
    • Apple Silicon. macOS 11 or later. (Download the iOS App from the iOS App Store)
    • Chromebook. Google Play Store required.
  • Other:

    • Leedh Processing lossless digital volume control
    • Programme of Continuous Development – Firmware-upgradable for further features and enhancements
